Noyafa NF-8209S Network Cable Tracker

Original price was: 9,700.00 ৳ .Current price is: 8,500.00 ৳ .

Model: Noyafa NF-8209S
Cable types: CAT5/CAT6
Locate The Target Cable Quickly
Measure Cable Length Accurately
Rechargeable Battery

Noyafa NF-8209S Advanced Network Cable Tracker

The Noyafa NF-8209S Network Cable Tracker is a professional-grade networking tool designed for IT technicians and network installers to efficiently test, trace, and diagnose Ethernet and telephone cables. It combines multiple functions such as wire mapping, cable tracing, PoE testing, length measurement, and port identification in a single portable device. With support for CAT5, CAT5e, and CAT6 cables, the NF-8209S can quickly identify common wiring faults including open circuits, short circuits, split pairs, and cross connections. Its cable length measurement capability helps estimate cable runs, while the dual scan modes (digital and analog) ensure accurate cable tracing even in complex environments.

The device also features advanced PoE detection, supporting IEEE 802.3af/at standards with voltage analysis from 5V to 60V, making it suitable for modern network installations. Additional features like port flashing, switch speed detection, and duplex identification make it easier to locate active network ports in large setups.

The receiver unit includes NCV (non-contact voltage detection), adjustable sensitivity, LED indicators, and audio output via headphone jack for enhanced usability in noisy environments. Powered by a rechargeable lithium battery, the NF-8209S is built for long working hours and field reliability. Overall, the Noyafa NF-8209S is an all-in-one network diagnostic solution ideal for professionals who need fast, accurate, and versatile cable testing and troubleshooting capabilities.

Product Name:	Advanced Network Cable Tracker
Model:	NF-8209S
Functions:	Cable tracing, wire mapping, cable length testing, PoE testing, port flash, continuity test
Compatible Cable Types:	CAT5, CAT5e, CAT6, STP/UTP network cables
Cable Mapping (Wiremap):	Detects open circuit, short circuit, cross, split pairs, and reversed wiring
Cable Length Range:	Approx. 2.5m – 200m (up to ~600m tracing range in some modes)
Scan Modes:	Digital mode, Analog mode (455KHz signal), PoE scan mode
PoE Test:	DC 5–60V detection, IEEE 802.3af/at compatible, polarity and mode detection
Port Features:	Port flash, switch identification, full/half duplex detection, speed detection (10/100/1000M)
Display:	Backlit LCD display (transmitter unit), multi-language support
Battery:	3.7V rechargeable lithium battery (approx. 1400mAh)
Receiver Features:	NCV (non-contact voltage detection 70–1000V), adjustable sensitivity, LED indicator, headphone jack
Connectivity Ports:	RJ45, RJ11 (depending on mode and adapter)
Safety Protection:	Voltage protection up to 60V DC input protection
Operating Temperature:	-10°C to 50°C (approx.)
Dimensions:	Approx. 125 × 70 × 32 mm (main unit)
Weight:	Approx. 200–300 g (set, estimated)
Color:	Black
Warranty:	No Warranty
